3
Satisfying your
performance needs
Adapt instrument configurations
to fit your test needs
• Internal voltage biasing up to ±40 Vdc 3
• High current biasing up to 40 A dc 3
(Agilent 4284A)
• Wide range of frequencies, 20 Hz to
30 MHz
• BIN’ing and comparator functions for
handlers
• SMD, axial and radial test fixtures 3
Simplify your system
development and integration
• Programming language compatible
with IEEE 488.2
• Test port extensions: maximum 4 m
for 4284A 3 and 2 m for 4285A
• Identical operation for the entire
family of products
• Scanner, handler and GPIB interfaces 3
Key specifications
Agilent 4285A precision LCR meter
Test frequency 75 kHz to 30 MHz with 100 Hz resolution
Measurement range 1
|Z|, R, X :0.01 m Ω to 99.9999 MΩ
|Y|, G,B :0.01 nS to 99.9999 S
C :0.01 fF to 999.999 µF
L :0.001 nH to 99.9999 H
D :0.000001 to 9.99999
Q :0.01 to 99999.9
Basic accuracy |Z|, C and L:0.1% D:0.001
Test signal level range
Voltage 5 mVrms to 2 Vrms
Current 200 µArms to 20 mArms
Constant test signal level range
Voltage 10 mVrms to 1 Vrms
Current 100 µArms to 20 mArms
Measurement time 2 30 ms/65 ms/200 ms
4285A with Option 4285A-001
Internal DC bias ± (1 mV ~ 40 V),
≤ 100 mA, 0.1% accuracy
4285A with Option 4285A-002, 42841A, and 42842C
DC current bias 0.01 A to 10 A
1. Refer to specifications for complete accuracy.
2. Supplimental information only.
3. The options, the accessories, or the test fixtures
are needed.
