Impedance parameters |Z|, |Y|, Ls, Lp, Cs, Cp, Rs, Rp, X, G, B, D, Q, θz [°],
θz [rad], θy [°], θy [rad]
(A maximum of four parameters can be displayed at one
time.)
Measurement range 200 m
Ω to 3 kΩ
(Frequenc y = 1 MHz,
Averaging factor = 8,
Oscillator level
≥ –33 dBm,
Measurement uncertainty ≤ ± 10 %,
Calibration is performed within 23 °C ± 5 °C,
Measurement is performed within
± 5 °C from the
calibration temperature
Range 1 MHz to 3 GHz
Resolution 100 kHz
Uncertainty ± 10 ppm (23 °C ± 5 °C)
± 20 ppm (5 °C to 40 °C)
3
Basic Measurement Characteristics
Measurement parameters
Measurement range
Source characteristics
Frequency
