Chapter 21

631

Safety and Regulatory Information and Specifications

E7495A/B Base Station Test Set Specifications

Safety and Regula

tory In

rmatio

Sp
ecification

Instrumentation Accuracy:

Absolute:

Relative:

± 0.02 dB (log) or ± 0.5% (linear) Add the
corresponding power sensor linearity percentage.
± 0.04 dB (log) or ± 1.0% (linear) Add the
corresponding power sensor linearity percentage.

Zero set accuracy:

Zero set is the digital zero with an 8482A sensor
± 50 nW

Power reference accuracy:

Power output:

Accuracy:
VSWR:

1.00 mW (0.0 dBm) traceable to the U.S. National
Institute of Standards and Technology (NIST).
± 1.2% worst case (± 0.9% rss) for one year
< 1.08

External attenuator:

Max power:
Attenuation:

100 watts
40 dB ± 0.5 dB

Power meter Option 600 with Agilent 8482A power sensor
(also supports Agilent 8481A power sensor)

Frequency Range:

100 kHz to 4.2 GHz

VSWR

100 kHz to 1 MHz:
0.3 MHz to 1 MHz:
1 MHz to 2 GHz:
2 GHz to 4.2 GHz:

< 1.60

< 1.20

< 1.10

< 1.3

Power linearity:

+ 10 dBm to +20 dBm; ± 3%

Maximum power:

300 mW average. 1 W peak, 30 W -

µsec per pulse

Measurement noise:

< 93.5 nW (0.85 + 110 nW)

Average filtering:

Fixed at 32 in normal mode

Zero drift:

< ± 10 nW

Table 21-2

E7495A/B Base Station Test Set Option Specifications
