10
Return loss module specifications with internal source
(When used with external sources the specifications of Agilent 81610A return loss module apply)
All modules require angled contact (8°) at input and output connectors
1. At 25 °C constant temperature, coherence control on,
warm-up time after laser turn on > 5 min
2. Averaging time 1 s
• calibration prior to measurement
• constant temperature
• coherence control on
• warm-up time after laser turn on > 5 min
• length of measurement patch cord ≤ 2 m
• angled connector in optimal optical condition
• Reference cable 81610CC used for total uncertainty
3. Use defaults settings (no user calibration necessary):
• length of measurement patch cord ≤ 2 m
• return loss of connectors ≥ 70 dB
4. For measurements performed immediately after calibration
5. Warm-up time 60 min, if previously not stored at the same temperature
Laser Safety
Information
The above products are classified as
Class 1 according to IEC 60825 1 (2001).
All laser sources comply with
21 CFR 1040.10 except for deviations
pursuant to Laser Notice No. 50,
dated 2001-July-26.
CLASS 1 LASER PRODUCT
(IEC 60825-1 / 2001)
Agilent 81613A
Source Fabry-Perot Laser (internal)
Output power Typ. –4 dBm ±1.0 dB typ.
Center wavelength 1 1310 nm/1550 nm ±20 nm typ.
Sensor element InGaAs
Fiber type Standard single-mode 9/125 μm
Dynamic range 75 dB
Relative uncertainty of
return loss (RL)
RL ≤ 55 dB
RL ≤ 60 dB
RL ≤ 65 dB
RL ≤ 70 dB
RL ≤ 75 dB
Total uncertainty
User calibration 2
< ±0.5 dB (typ. < ±0.3 dB)
< ±0.6 dB (typ. < ±0.4 dB)
< ±0.8 dB (typ. < ±0.5 dB)
< ±1.9 dB (typ. < ±0.8 dB) 4
Typ. < ±2.0 dB 4
Add ±0.2 dB
Plug and play 3
Typ. < ±0.6 dB
Typ. < ±1.5 dB
Add typ. ±0.2 dB
Maximum safe input power +16 dBm
Dimensions (H x W x D) 75 mm x 32 mm x 335 mm (2.8” x 1.3” x 13.2”)
Weight 0.6 kg
Recommended recalibration period 2 years
Operating temperature 10 °C to 40 °C
Humidity Non-condensing
Warm-up time 5 20 minutes
