Alpha Technologies VMX Series User Manual
Page 37
37
017-940-B0-001, Rev. A
Fig. 5-4, Setup Menu Display
(Examples are given for values in the display)
5.0 Operation,
continued
5.2
Smart Display, continued
5.2.3
Setup Menu, continued
SETUP MENU
FLOAT V/C
2.27
ACCEPT V/C
2.40
TEMP COMP
5mV
BATT CAPACITY
100Ah
SELF-TEST OFF
TEST INHIBIT
—
TEST INTERVAL
30 D
TEST COUNTDOWN
3 D
TEST DURATION
10 M
FREQ RANGE
3.0HZ
RESET OUT 1
NO
RESET OUT 2
NO
RESET OUT 3
NO
RESET OUT 4
NO
PEAK CURRENT 1
15A
PEAK CURRENT 2
15A
PEAK CURRENT 3
15A
PEAK CURRENT 4
15A
RMS CURRENT 1
15A
RMS CURRENT 2
15A
RMS CURRENT 3
15A
RMS CURRENT 4
15A
PEAK RETRY DELAY
60S
PEAK RETRY LIMIT
10
PEAK CURRENT TOLERANCE 40MS
RMS RETRY DELAY
300S
RMS RETRY LIMIT
10
RMS CURRENT TOLERANCE 60S
STANDBY TIME
65 M
STANDBY EVENTS
12
SET DEFAULTS
NO
CODE VER
2.00.0
VMX_CLASS VER
6
DEVICE ADDRESS
1
TOTAL RUN TIME
365D
LANGUAGE ENGLISH
