5.0 Operation, continued
5.2 Smart Display, continued
5.2.2 Additional Information Display
Press ENTER to activate the Additional Information display, which is an extension
of the Normal Operation mode and displays information of secondary importance to
the operator. When the Additional Information display is fi rst accessed, information
is displayed in the Auto Scroll mode. Pressing UP or DOWN allows the information
to be accessed one step at a time. Pressing ENTER will access the Setup Menu
(discussed in Section 5.2.3, Setup Menu). Pressing ESCAPE reactivates Auto Scroll
mode. Pressing ESCAPE a second time reactivates the Normal Operation display
(up one level).
The Additional Information display contains the following items:
Top Line (Provides additional instructions):
• ADDITIONAL INFO
• TO MANUAL SCROLL
• TO SETUP MENU
• TO SYSTEM INFO
Second Line (cycles through the following parameters):
• BATTERY TEMP xx ° C
• CHARGER CURR xx.x A
• INPUT FREQ xx.x HZ
• OUTPUT WATTS xxx W
• OUTPUT VA xxx
• PERCENT LOAD xx%
• INPUT CURRENT xx.xA
Fig. 5-3, Additional Info Display
(Examples are given for values in the display)
ADDITIONAL INFO
BATTERY TEMP
37°C
CHARGER CURR 8.2A
INPUT FREQ 60HZ
OUTPUT WATTS 900W
OUTPUT VA 1060
PERCENT LOAD 80%
INPUT CURRENT 5.6A
Lower case italicized items indicate variables that change according to the operating mode, setup, or
measured values. These items appear as normal UPPER CASE text in the actual display. INPUT FREQ is not
valid during inverter operation.
NOTE:
