36 017-940-B0-001, Rev. A
5.0 Operation, continued
5.2 Smart Display, continued
5.2.3 Setup Menu, continued
The Setup Menu contains the following items:
Top Line (provides additional information)
• SET UP MENU
• TO MANUAL SCROLL
• TO ADD’L INFO
Second Line (cycles through the following parameters):
Refer to Section 5.3, Smart Display Glossary, for descriptions of the setup menu parameters.
NOTE:
Default Minimum Maximum
Float V/C 2.27 2.1V/Cell 2.35V/Cell
Accept V/C 2.40 2.2V/Cell 2.45V/Cell
Temp Comp 5mV/Cell/ºC 0mV/Cell/ºC 5mV/Cell/ºC
Battery Capacity* 100Ah 0Ah 1000Ah
Self-test Off On Off
Test Inhibit N/A 7 days 7days
Test Interval 30 days 0 days 360 days
Test Countdown 0 days 0 days 360 days
Test Duration 10 minutes 5 minutes 180 minutes
Frequency Range 3Hz 1Hz 6Hz
Reset Out 1 No Yes
Reset Out 2 No Yes
Reset Out 3 No Yes
Reset Out 4 No Yes
Peak Current 1 Rating of the unit (15A or 22A) 3A 25A
Peak Current 2 Rating of the unit (15A or 22A) 3A 25A
Peak Current 3 Rating of the unit (15A or 22A) 3A 25A
Peak Current 4 Rating of the unit (15A or 22A) 3A 25A
RMS Current 1 Rating of the unit (15A or 22A) 3A 25A
RMS Current 2 Rating of the unit (15A or 22A) 3A 25A
RMS Current 3 Rating of the unit (15A or 22A) 3A 25A
RMS Current 4 Rating of the unit (15A or 22A) 3A 25A
Peak Retry Delay 60s 5s 301s
Peak Retry Limit 10 0 (retry disabled) 40
Peak Current Tolerance 40ms 20ms 9900ms
RMS Retry Delay 300s 60s 600s
RMS Retry Limit 10 0 10
RMS Current Tolerance 60s Read Only Read Only
Standby Time 0 minutes 0 minutes 65,535 minutes
Standby Events 0 events 0 events 65,535 events
Set Defaults No No Yes
Code Version 2.00.0
VMX_Class Version 6
Device Address 1 0 7
Total Runtime 0 days 0 days 65,535 days
Language English Spanish, French, German, Portuguese
* 100Ah = 1 battery string, 200Ah = 2 battery strings, 300Ah = 3 battery strings
Table 5-1, Setup Menu Parameters
