Alpha Technologies LPE Enclosure User Manual
Page 17
031-302-B0-001 Rev A
17
2.0
Installation, continued
2.3
Enclosure Installation, Ground-mount, continued
2.3.3 Ground-mount Installation, continued
Fig. 2-4, LPE Enclosure Pedestal
Fig. 2-5, Enclosure-to-Pedestal Mounting
PEDESTAL ANCHOR HOLES
PAD
OUTSIDE OF PEDESTAL
INNER FLANGE
PEDESTAL ANCHOR HOLES
ENCLOSURE MOUNTING HOLES
13.75
349.25
8.00
203.20
11.26in
286.08mm
1115.14mm
43.90in
509.93mm
20.08in
18.00in
457.20mm
