10 031-302-B0-001 Rev A
1.0 Introduction, continued
1.2 LPE Specifications and Options
Specifications
Mechanical Option Part Number Description
Dimensions Battery Harness: 875-838-20
746-152-20
12V Battery Cable Kit (BCK)
12V Battery Cable Kit - 2 Batteries
(BCK-2)
H x W x D (in): 26 X 16.25 X 12 Battery Heater Mat 746-130-20 Used in cold-climate applications
(mm) 660 X 413 X 305 Battery Retaining Bar (BRB) 605-948-A1 Secures batteries within enclosure
Weight (lb/kg): 25 / 11.3 Coax Connection: 020-019-35 SPI, 20A (1-2)
021-080-21 SPI RF, 20A (1)
SPI, 20A (1-2)
Material: Exterior powdercoated
aluminum
Door Locks: 744-229-20 Provisions optional GEM
Battery: 220 GXL or two 70 HPL-FT Lightning Arrester 020-098-24
162-046-10
745-946-20
LA-P+ 120V
LA-P-120T
Surge Arrester Kit
Door and Lid Seal: Poron gasketing Service Entrance: 744-656-20 70A available
Color: Gray, white, and seafoam
green
Status Indicators: 740-139-25 Local/Remote Indicator (LRI)
Lid: Removable Surge Protection: 162-027-10
162-028-10
162-029-10
75 Ω Coax, MF
75 Ω Coax, FF, w/Gnd
75 Ω Coax, FF
Door: Hinged, removable
