2.0 Installation
Fig. 2-1, Dimensions, pole-mounted NPS Enclosure
16.25"
SPI
Upper mounting strap
Enclosure ground point
Lower mounting strap
Service entrance
4.0"
Knockouts for optional ACI, LRI indicator Lamps
Lockable door latch
Optional GEM lock
Hinged, removeable door
6
2
1
3
4
7
8
6
3
2
4
5
8
9
7
9
2.1 Pole-mounted version
2.1.1 Dimensions and features
24.85"
14.1"
17.00"
1
5
