5.4 Factory Ranges and Defaults
The following table lists the rectifier settings/ranges/defaults; changes are made via the CXC:
Setting Range (minimum to maximum) Default
Float Voltage 47.5 – 58.2V 54V
Equalize Voltage 49.8 – 60.2V 55V
Battery Test Voltage 44 – 52V 46V
OVP See note below – 63V 57V
Current Limit 23 – 100% 100%
Power Limit 0 – 100% 100%
Module Start Delay 0 – 250s 1s
System Start Delay 0 – 600s 0s
Low Voltage Alarm 42 – 52V 44V
High Voltage Alarm 52 – 63V 55.5V
Equalize Timeout 1 – 2399h 30h
Battery Test Timeout 1 – 250h 8h
Softstart Ramp-rate Normal/Fast Normal
CL/PL Alarm Enable/Disable Enable
Remote Shutdown Enable/Disable Enable
Ramp Test Enable/Disable Enable
Table C–Cordex 48-1kW Rectifier factory ranges and defaults
NOTE: OVP cannot be set below the present system voltage, float voltage setting, eq voltage setting, battery test voltage
setting or the safe mode voltage of 51.4V.
