83
English
Predefined presets:
The following table lists the presets that can only be called and not configured.
Predefined
presets
Function
Predefined
presets
Function
33 Automatic reversal 93 Define restrictions manually
34 Return to initial position 94 Remote restart
35 Call tour 1 95 Call on-screen display menu
36 Call tour 2 96 Stop scanning
37 Call tour 3 97 Start random scan
38 Call tour 4 98 Start frame scan
39 IR cut filter on 99 Start auto scan
40 IR cut filter off 100 Start inclination scan
41 Call pattern 1 101 Start panorama scan
42 Call pattern 2 102 Call tour 5
43 Call pattern 3 103 Call tour 6
44 Call pattern 4 104 Call patrol 7
92 Start restrictions 105 Call patrol 8
10.4.3 Patrol settings
A patrol consists of a series of presets. You can create 8 patrols with up to
32 presets
To create a new patrol, proceed as follows:
Select the Patrol tab. Select the desired patrol. To add presets to
the patrol, click on the button.
Select the desired preset and set the patrol duration and speed.
Please remember that the presets that can be added to a
patrol are predefined.
Patrol Duration Dwelling time at a preset position.
After the time has elapsed the
camera switches to the next preset.
Patrol Speed Set the speed of motion to the next
preset.
