ABUS TVIP82x00 Operating instructions - Manual (Page 82)

82
English
10.4 Camera control
10.4.1 PTZ control
To display the PTZ control, in the live cast click on the field.
Button Description
Arrow buttons:
Control of the swivel / inclination motions
Start / stop 360° rotation
Zoom in / out
Close / remote focus
Light adjustment aperture
Adjustment of PTZ speed
Activate IR illuminator (not available)
Activate wiper (not available)
One-touch focus (not available)
Lens initialisation (not available)
10.4.2 Preset settings
Select the Preset tab to be able to call up, set and delete up to 256 preset positions. Use the
PTZ control buttons to select the desired preset position.
Click on the button to save the preset.
Button Description
Selection of the desired preset position. The select
preset has a blue background
Call up the position
Create the position
Delete the position
