9
5.1 Teaching radio components
1. Put the expansion module into learn mode if you have
not already done so.
2. Make sure that the LED of the radio components to be
taught points to the learn sensor at a maximum
distance of 100 mm.
3. Activate the radio components (when necessary by
releasing the tamper switch). The LED must thereby
point to the learn sensor of the expansion module.
The expansion module emits a double beep when the
radio component has been successfully taught.
Detectors that have been taught now show the signal
strength on the left (max. 9) and the channel number on
the right. The channel is assigned automatically.
A taught panic alarm or remote control shows the
number of learnt components by displaying„
„
alternately to the signal strength.
If the radio component can not be taught then the
expansion module emits a single beep.
4. Repeat steps 2 and 3 to teach additional radio
components. Please observe that a maximum of 6 radio
remote controls or panic alarms can be taught.
5.2 Assigning detectors to particular zones
1. Put the expansion module into learn mode.
2. Press the „SELECT“ button until the required zone is
displayed. If the display flashes then the zone is not
assigned (free). If the display is constant then the zone
is assigned.
3. Now carry out steps 2 and 3 as described in „Teaching
radio components“.
5.3 Deleting detectors
1. Put the expansion module into learn mode.
2. Press the „SELECT“ button until the required zone is
displayed.
3. Press the „DELETE“ button for approx. 4 seconds. A
double beep is emitted and the detector is deleted.
5.4 Deleting remote controls
These components can not be deleted individually. To delete a
component, all radio remote controls and panic alarms must be
deleted.
