ABUS AZ4250 Terxon LX 8-zone Wired Extension with PSU User Manual
Page 3
3
3.
Beschreibung der Komponenten und
Programmierung
1.) Nicht verwendet
2.) ZONENVERDRAHTUNG
Jede Zone kann unterschiedlich verdrahtet werden. Die Kontakte der
Melder sind üblicherweise NC (normal geschlossen); falls Sie das
Verhalten NO (normal offen) wünschen, müssen Sie die Zonen
invertieren.
Hinweis: Die Spannungsversorgung der Melder erfolgt über zwei
zusätzliche Leitungen für die Verbindungen zu den Anschlüssen AUX
(+12V DC / 0V).
