ABUS AZ4250 Terxon LX 8-zone Wired Extension with PSU User Manual
Page 11
11
4. Technical
data
External voltage supply
230 VAC +/- 10%, 50 Hz
External power consumption
145 mA
Internal voltage supply
13.8 V DC
Internal power supply
1.5 A (750mA for battery charge)
Internal power consumption
60 mA max. at 12 V DC;
305 mA max. with loudspeaker
Standby battery
12 V DC, 7Ah/17Ah battery
Zones
8 zones; NC or FSL with anti-
masking
Output
1 output positively switching (+1),
500 mA max. at 12V DC
Fuses
4 fuses (500 mA) automatically
resettable; 1 mains fuse (315 mA
slow)
Dimension
382mm x 310mm x 95mm (HxWxD)
Weight 4.5
kg
Operating temperature
-10° to 55°C
Operating humidity
Max. 96%
