Elmo Rietschle G-BH1e - Manual (Page 44)

610.44521.40.000 44 / 52 © Gardner Denver Deutschland GmbH
Servicing
8.1.3 Fault indication at the keypad
Keypad
(PC) 1)
Malfunction Cause Remedy Carried
out by
Strong interferences on control
cables Shield control cables ccr

(71) System fault
Ground or earth loops in the
wiring Remove ground or earth loops.
Electrician
ce1

(62) Communication
fault to CAN−IN1
with Sync control CAN−IN1 object receives faulty
data or communication is
interrupted  Check if the bus module is
correctly plugged on.
 Check transmitter
Service
ce2

(63) Communication
error to CAN−IN2 CAN−IN2 object receives faulty
data or communication is
interrupted  Check if the bus module is
correctly plugged on.
 Check transmitter
Service
ce3

(64) Communication
error to CAN−IN1
with event or time
control CAN−IN1 object receives faulty
data or communication is
interrupted  Check if the bus module is
correctly plugged on.
 Check transmitter
Service
ce4

(65) BUS−OFF (many
communication
errors occurred) Frequency inverter has
received too many ncorrect
telegrams via the system bus
and has been disconnected
from the bus  Check if there is a bus
termination.
 Check shield contact of the
cables
 Check PE connection Check
bus load, if necessary, reduce
the baud rate
Service
ce5

(66) CAN time−out For remote parameter setting
via system bus (C0370):
Slave does not reply. The
communication check time has
been exceeded  Check system bus wiring
 Check system bus
configuration
Service
ce6

(67) Function module
system bus (CAN)
attached to the
control interface is
set to "Warning"
or "BUS−OFF" CAN controller signals
"Warning" or "BUS OFF"  Check if there is a bus
termination.
 Check shield contact of the
cables
 Check PE connection
 Check bus load, if necessary,
reduce the baud rate
Service
ce7

(68) Communication
fault during
remote parameter
setting via system
bus (C0370) Bus device does respond or is
not available  Check if there is a bus
termination.
 Check shield contact of the
cables
 Check PE connection
 Check bus load, if necessary,
reduce the baud rate
Service
EEr

(91) External fault External encoder signals an
error
(terminal X3/E2 = LOW) Remove external error.
Then reset error EEr by:
 Mains switching
 or X3/E1 = HIGH (TRIP-
Reset)
Operator
ErP0
…
ErP19
 Communication
abort between
keypad and basic
device Various Contact manufacturer
H05

(105) Internal fault Contact manufacturer
