Commissioning
Changing and saving parameters
All parameters for parameterization or monitoring of the controller are stored in codes. The codes are
numbered and marked with a "C" in the documentation. The available codes are listed in the code
table.
Step Keys Result Action
1. Connect keypad 
XX.XX
Hz
The function  is active.
C0140 = setpoint is indicated via keypad.
2.   Select mode ".
3.  XXXX Select code..
4.   Modus  off Ahlen.
5.  xxxxx Parameter onstellen.
 Store Confirm entry when ! is blinking. 6.
 Confirm entry when ! is not blinking;  is inactive.
7.
Set parameters
 Start "loop" again at 2. for further parameter setting.
Changed parameters are stored in the non−volatile memory of the controller.
5.2.2 Code table
How to read the Code table
Column Abbreviation Meaning
Cxxxx Code number Cxxxx The parameter value is accepted
immediately (ONLINE)
 Changed parameter of the code will be accepted after pressing 
Code
 Changed parameter of the code will be accepted after pressing  if
the controller is inhibited
Designation Name of the code
Manufacturer Default setting (value at delivery or after restoring default setting via
C0002)
 Further information can be obtained from "IMPORTANT"
Selection 1 {%} 99 Min. value {unit} max. value
IMPORTANT - Brief, important explanations
Code Possible settings IMPORTANT
No. Designation Manu-
facturer Selection
C0140 Setpoint offset via
keypad
0,00 -650,00 {0,02 Hz} 650,00 Acts additively on
 main setpoint.
 setpoint 2.
 fixed speeds (JOG).
The set value is stored in case of
mains switching or keypad
removal.
C0050 Output frequency -650,00 {Hz} 650,00 Display only: Output frequency
without slip compensation
C0052 Motor voltage 0 {V} 1000 Display only
C0054 Apparent motor
current
0,0 {A} 2000,0 Display only
