© Gardner Denver Deutschland GmbH 35 / 52 610.44521.40.000
Commissioning
Display elements and function keys
z
y
w x
v
t
u
s
88888
8888
888
8
a b c d e
j g f k i h PS 
‚m n o p
q r
Hi
Hz
%sh
rpm
°C Ω
m
A V
Lo
6
0
3
1
2
4
5
n_e2fcx002
Fig. 24: Display elements and function keys
Status displays

Meaning Explanation
 Ready
 Pulse inhibit active Power outputs inhibited
 Adjusted current
limitation is
exceeded in
motor−mode or
generator mode C0022 (motor mode) or
C0023 (generator
mode)
 Warning active

 Fault active
Function bar 1

Meaning Explanation
 Without function Display = loc
 Display of first code
in the menu Active after every mains
connection
 Code selection Four−digit display of the
active code number
 Without function Is skipped
 Change of
parameter value of
a code Five−digit display of the
current value

 Without function
Function bar 2

Not active
Bar graph display

Controller load Display range: −180 %
... +180 % (each
graduation mark = 20
%)

Display of code number

Display of parameter value or fault indication
Function keys
Function Explanation
 Enable controller Terminal X3/28 must
additionally be at HIGH
level
 Inhibit controller
 Change function bar
1 function bar 2 Function bar 2 not
active
 To right/left in active
function bar The active function is
framed
 Increase/decrease
value
Fast change: Keep
respective key
pressed Only blinking values
can be changed

 Store parameters
when ! is blinking
Confirmation by
Store in display
