Commissioning
Code Possible
settings IMPORTANT
No. Designation
Manu-
facturer
Selection
C0010 Minimum output
frequency
10,00
0,00
{0,02 Hz}
650,00 C0010 only limits the analog input 1
Only valid for units 2BH.−..N.1−.
and 2BH.−..N.3−.with integrated
2FCxxxx−1NE00 inverter
C0011 Maximum output
frequency
86,00 7,50 {0,02
Hz}
650,00 Maximum permissible value: 86
(5000/min)
Only valid for units 2BH.−..N.1−.
and 2BH.−..N.3−.with integrated
2FCxxxx−1NE00 inverter
10,00
Setting for units up to 5.5 kW
25,00
Setting for 7.5 kW unit
C0012 Acceleration time
main setpoint
0,00
{0,02 s}
1300,00 Reference: frequency change 0 Hz ...
C0011
Only valid for units 2BH.−..N.1−.
and 2BH.−..N.3−.with integrated
2FCxxxx−1NE00 inverter
10,00
Setting for units up to 5.5 kW
20,00
Setting for 7.5 kW unit
C0013 Deceleration time
main setpoint
0,00
{0,02 s}
1300,00 Reference: frequency change 0 Hz ...
C0011
Only valid for units 2BH.−..N.1−.
and 2BH.−..N.3−.with integrated
2FCxxxx−1NE00 inverter
52,70
Setting for units 2BH.−..N.3−.
90,90
Setting for units 2BH.−..N.1−.
C0015 U/f−rated
frequency
7,50
{0,02
Hz}
960,00
]
[
*
]
[
]
[
]
[
0015
Hz
f
V
U
V
U
Hz
C
r
r
N
U
N
= mains rated voltage of
inverter
U
r
= rated voltage of motor
depending on connection method
acc. to rating plate
f
r
= rated frequency of motor acc.
To rating plate
The setting applies to the entire
mains voltage range in which the
inverter may be operated.
C0016 U
min
boost (starting
voltage
0,00
{0,01
%}
40,00
Depends on the device
Load−independent rise of motor
voltage at low speeds:
Reference: rated voltage of motor
(C0090).
The setting applies to the entire
mains voltage range in which the
inverter may be operated.
