PDPF-10-XBAFFLE
10” PDPF
High Elevations
®
Performance Downlight Cross Baffle Pendant, Horizontal Triple-Tube Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
EL
EC
TR
IC
AL
Aperture:
9-3/4 (24.8)
Overall Diameter:
11-3/8 (28.9)
Height:
19-3/8 (49.2)
Annual*
Energy
Cost
$7.36
$7.48
$8.37
$7.54
Lamps
(2) 32W TRT
(2) 42W TRT
(3) 32W TRT
(3) 42W TRT
Lamp
Lumens
4800
6400
7200
9600
0.96
0.95
1.00
1.00
Input
Watts
69
94
105
139
*
Comparative yearly lighting energy cost per 1000 lumens
LER.DVH
33
32
29
32
Ballast
Factor
ENERGY
(Calculated in accordance with NEMA standard LE-5A)
