Page 9
1-3
TPS150 Switching and Transmission System • Introduction
The audio for the selected input is output locally. It is not sent to the receiver.
The TPT150 has an RS-232 port that accepts ICS100 program control from a
connected computer or serial command control from a computer or control system.
The transmitter can also store serial commands that are entered by the operator.
The transmitter sends the appropriate serial commands on the TP link to the
receiver whenever an input button or the projector power button is pressed.
An optional CTP150CM control panel can be connected to a contact closure port on
the TPT150. Using the CTP150CM, a remote operator can select inputs, power up
and down a projector connected to the receiver, and increase and decrease the
output volume.
+
-
+
R
L
-
GND
PR
OJ PWR
VO
L DN
VO
L U
P
IN4
IN3
IN2
IN1
LOCAL MONIT
OR
OUTPUT
AU
DIO
L
R
RGB /
VG
A
RGB /
VG
A
INPUT 2
INPUT 1
INPUT 3
R-Y
B-Y
Y
VIDEO
AU
DIO
S-VIDEO
AU
DIO
L
R
L
R
INPUT 4
OUTPUT
REMO
TE
CONTR
OL
RS-232 POR
T
AU
DIO
R-Y
B-Y
Y
VIDEO
AU
DIO
S-VIDEO
L
R
UPT LINK
FUSE:
1.6A;
250V
; TI
ME DELA
Y
TEC
HNICA
L SU
PPO
RT
:
(800
) 882
-7117
(714) 450-1800
www
.inlineinc.com
!
FU
SE:
1.6
A;
250
V;
TI
ME DEL
AY
90-260V
AC;
0.25A;
47-63Hz
UTP LINK
SKEW
RGB /
VG
A
COMPOSITE
VIDEO OUTPUT
S-VID
EO
COMPONENT
RS-232 POR
T
R-Y
B-Y
Y
R E
D
B L
U E
G
R N
ADJ
TEC
HNICAL S
UPPOR
T:
(800) 882-7117
(714)
450-1800
www
.Extr
oninc.com
MADE IN U
.S.A.
TP
Cable
Control
System
Sound
System
DVD
Component
Video
VCR
Composite
Video
Laptop
PC
Input 4
Input 3
Input 2
Input 1
Extron
CTP150CM
Control
Panel
Extron
TPT150
AV Switcher
Extron
TPR150
Twisted Pair
Receiver
INPUT 1
INPUT 2
INPUT 3
INPUT 4
VO
LUME
VO
LUME
PR
OJECT
OR
PO
WER
Figure 1-1 — Typical TPS150 Switching and Transmission System
application
About the TPR150 receiver
The TPR150 receiver accepts the TP link from the transmitter and outputs the
received video and RS-232 commands. The receiver outputs the following signals
on the following connectors:
•
High-resolution RGB video
on one female 15-pin HD connector
•
Component video (Y, R-Y, B-Y)
on three female RCA connectors
•
S-video
on one female 4-pin mini DIN connector
•
Composite video
on one female RCA connector
•
Serial (RS-232) commands
on one male DB9 connector
