Extron Electronics TPS150 User Guide User Manual
Page 45
4-17
TPS150 Switching and Transmission System • Serial Communications
Command/response table for programming and operating the TPT150 (Cont’d)
Command
ASCII Command Response
Additional description
(host to switcher)
(switcher to host)
Front panel lockout
Disable front panel
[FP0]
[R0•
X1
•FP0•]
Disable the transmitter’s buttons.
Enable front panel (default)
[FP1]
[R0•
X1
•FP1•]
Enable transmitter’s buttons.
Toggle front panel lockout
[FP]
[R0•
X1
•FP•]
Toggle front panel status
(enabled-to-disabled or disabled-
to-enabled).
View front panel lockout
[FP?]
[R0•
X1
•FP?•
X3
]
0 = front panel off, 1 = on.
Transmitter reset
Reset transmitter
[DFLT
X16
]
{none}
0 = reset serial port settings and
addresses without deleting input
button codes, projector power
codes, input audio level, and
volume.
1 = factory reset, including input
codes, projector power codes,
input audio levels, and volume
level.
Architectural information
View architectural information
[ARC]
[R0•
X1
•ARC•
X17
]
Display the transmitter model,
revision, and connection
information.
