Operation, cont’d
TPS150 Switching and Transmission System • Operation
3-8
Specific problems
The table below shows some common operating problems and their solutions.
Problem
Possible cause
Solution
No image appears.
System is not receiving Ensure that the video source, the
power.
transmitter and receiver, and the
display are plugged into a live AC
power source and the transmitter
is turned on.
No video input
Check that the input device is
sending a video signal to the
transmitter.
No video output
Select a different input. If a screen
display does not appear, check the
output connection.
The projector has the
On the projector, manually check
wrong input/signal
that the input and format are
format selected.
correct. If not, check that the
proper signal string for the input
selection is programmed into the
transmitter.
Video may be muted.
Press the transmitter’s Blank
button to disable video mute.
Distorted image
Improperly adjusted
Follow the steps in “Optimizing
appears.
receiver
the Video” on page 3-6.
