Extron • SENTOSA xi LQ & LANCIA xi LD • User’s Manual Page 3-3
Time-out
Pauses 10 seconds or longer between command sequence ASCII
characters will result in a Time-out. The command operation is
aborted with no other indication that a Time-out has occurred.
Error Responses
When a command is received from the Host, if the Sentosa xi /
Lancia xi detects an error, it will return an error response. Possible
error responses with a brief description follow:
• E01 Invalid input channel number (out of range)
• E06 Auto-switch mode active (rear panel DIP switch #1 =enable)
• E10 Invalid command (Command received is invalid)
• E13 Invalid value (out of range)
Sentosa xi xixi xixi /Lancia xi xixi xixi -Initiated Messages
When a local event takes place, such as a front panel operation or
an error condition, the Sentosa
xi /Lancia xi responds by sending a
message to the Host. No response from the Host is expected.
These Sentosa
xi /Lancia xi -initiated messages are listed below
(underlined to identify actual message).
(C) Copyright 1998, Extron Electronics (Model), V x.xx
This message is initiated by the Sentosa xi /Lancia xi when it is first
powered on. (Model = Sentosa xi or Lancia xi ), (x.xx is the software
version number)
Reconfig
RS-232 - Overrun
RS-232 - Noise
RS-232 - Framing
RS-232 - Overflow
RAM Test Failed
ROM Checksum Failed
Serial EEPROM Checksum Failed
6811 EEPROM Checksum Failed
New 6811 Installed
New Serial EEPROM Installed
Invalid Jumpers - Unknown - xxxx
Factory Defaults Reset on Channel #1
Factory Defaults Reset on Channel #2
RS-232/REMOTE Control
These Sentosa xi /Lancia xi -initiated messages
indicate an RS-232 communication error.
Possible causes are RS-232 connection
problem, Baud rate, etc.
Call Extron Technical Support if
any of these Sentosa
xi /Lancia xi -
initiated messages are reported.
Call Extron Technical Support.
Reported if Freeze button is
depressed during power-up.
This message is initiated by the Sentosa xi /Lancia xi
when there is a change in the selected input or any
picture control setting.
