Page 28
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Skew adjustment
Set all skew values for
an input
EX!
*
X%
*
X%
*
X%
Iseq
}
Set specific skew adjustment values for TP input X!.
X% values are listed in RGB order.
Iseq
X!
*
X%
*
X%
*
X%]
Example:
E
2*0*0*4Iseq
}
Iseq02*00*00*04
]
Set input 2’s skew settings as follows:
Red = 0 ns
Green = 0 ns
Blue = 8 ns (delayed 8 ns)
Increment one skew
value for an input
EX!
*
X^
+Iseq
}
Iseq
X!
*
X%
*
X%
*
X%]
Increase input
X!
’s
X^
plane’s skew value by 1 step
(2 ns).
Decrement one skew
value for an input
EX!
*
X^
-Iseq
}
Iseq
X!
*
X%
*
X%
*
X%]
Decrease input
X!
’s
X^
plane’s skew value by 1 step
(2 ns).
Example:
E
2*2-Iseq
}
Iseq02*00*00*03
]
Decrease input 2’s blue skew by 2 ns to 6 ns.
Read skew values
EX!
Iseq
}
X%
*
X%
*
X%]
RS-232 insert enable
Disable the RS-232 insert
E
1*0Lrpt
}
Lrpt0
]
Disable the RS-232 insert.
Enable the RS-232 insert
E
1*1Lrpt
}
Lrpt1
]
Enable the RS-232 insert.
Read the RS-232 insert
status
E
1Lrpt
}
X&]
Audio/RS-232 TP input (wire pair 3 and 6) configuration
NOTE:
The RS-232 insert, when enabled (
E
1*1Lrpt
}
), overrides the audio/RS-232 TP input configuration.
Configure input as audio
X!
*0\
Typ
X!
*0
]
Define the audio/RS-232 input as audio, such as
provided by an MTP 15HD A transmitter.
Configure input as
RS-232
X!
*1\
Typ
X!
*1
]
Define the audio/RS-232 input as bidirectional
serial communications, such as provided by an
MTP 15HD RS transmitter.
Show TP input
configuration
X!
\
X*]
Show the audio/RS-232 wire pair input definition.
Audio input gain and attenuation level
NOTE:
The set gain (G) and set attenuation (g) commands are case sensitive. The increment, decrement, and read commands are
not case sensitive.
Set the input audio gain
to a +dB value
X!
*
X(
G
In
X!
•Aud
X1)]
Example:
1*2G
In01•Aud+02
]
Set input 1 audio gain to +2 dB.
Set the input audio
attenuation to a -dB value
X!
*
X1!
g
In
X!
•Aud
X1)]
Increment gain
X!
+G
In
X!
•Aud
X1)]
Increase gain by 1 dB.
Example:
5+G
In05•Aud+03
]
Increase audio input 5 level from +2 dB to +3 dB.
Decrement gain
X!
-G
In
X!
•Aud
X1)]
Decrease gain by 1 dB.
Example:
7-G
In07•Aud-09
]
Decrease audio input 7 level from -8 dB to -9 dB.
Read input level
X!
G
X1)]
NOTE:
X!
= Input number
1-6
X%
= Skew adjustment range
00 - 31 (each step = 2 ns)
X^
= Video plane
0 = red
1 = green
2 = blue
X&
= RS-232 insert status
0= disabled
1 = enabled
X*
= Audio/RS-232 wire pair input type
0 = audio
1 = RS-232
X(
= Video plane
0 = red
1 = green
2 = blue
X1)
= RS-232 insert status
0= disabled
1 = enabled
X1!
= Audio/RS-232 wire pair input type
0 = audio
1 = RS-232
Command/response table for SIS commands (continued)
MTP SW6 • Remote Control
24
