Lanciaxi xi xi xi xi • RS-232/Remote Control
RS-232/Remote Control, cont’d
Windows-Based Program Control
The Signal Enhancement Control Program is Windows
compatible and provides remote control of the following:
• Input selection
• Video adjustments
• Freeze frame control
Installing the software
The program is contained on a single 3.5” diskette and can be
run from the floppy drive, or it can be installed and run from
the hard drive.
To install the software on the hard drive, run setup.exe from the
floppy disk and follow the screen instructions.
By default, the Windows installation creates a C:\S_ENHANC
folder and places two icons (Signal Enhancement Products
Control Program and Signal Enhancement Products Help) into a
group named “Extron Electronics”.
Using the software
1 . To run the software, double click on the Signal
Enhancement Products Control Program icon
in the Extron Electronics program group.
2 . Click on the comm port that is connected to the Lanciaxi ’s
RS-232 port.
3 . Extron’s Signal Enhancement Products Control Program
window (figure 7) displays current input selection (red
dot) and control values, as well as the slider controls.
Figure 7 — Signal enhancement program window
Using the help system
For information about program features, you can access the help
program in any of the following ways:
