Lanciaxi xi xi xi xi • Specifications
Specifications, cont’d Specifications
Video input
Number/signal type ................... 1 S-video, 1 composite video
Connectors .................................... 1 4-pin mini-DIN female (S-video)
1 BNC female (composite video)
Nominal level(s) .......................... S-video ..... Y: analog — 0.7V p-p
..... C: analog — 0.3V p-p (burst)
Composite ..... analog — 0.7V to 1.0V p-p
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Video output
Number/signal type ................... 1 RGBHV (non-interlaced)
Connectors .................................... 5 BNC female
Nominal level .............................. 0.7V p-p
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
DC offset ....................................... ±0.1V maximum
Sync
Output type .................................. RGBHV, RGBS, RGsB
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Output level ................................. TTL ....... 4.0V to 5.0V p-p
Output impedance ...................... 75 ohms
Horizontal output frequency .... NTSC 3.58/4.43 31.5 kHz
PAL/SECAM 31.25 kHz
Vertical output frequency* ........ NTSC 3.58/4.43 60 Hz*
PAL/SECAM 50 Hz*
*When VGA mode is active, vertical
frequency is forced to 60 Hz with any video
input.
Polarity ............................................ H & V ..................... positive or negative
(DIP switch-selectable)
.......................................................... Compositesync .... negative
Control/remote
Serial control port ....................... RS-232 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
RS-232 pin configurations ......... 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 9-pin female D connector
Program control .......................... Extron’s control program for Windows
Extron’s Simple Instruction Set – SIS
