ii Lanciaxi xi xi xi xi • Table of Contents
Table of Contents, cont’d
68-254-01 F
Printed in the USA
11 00
All trademarks mentioned in this manual are the properties of their respective
owners.
Contact Closure Control ..................................................... 4-7
Appendix A • Specifications,
Accessories, and Part Numbers
........ A-1
Specifications ......................................................................... A-2
Included Parts ......................................................................... A-3
Accessories ............................................................................... A-3
Cables ......................................................................................... A-3
Lanciaxi xi xi xi xi • Specifications A-3
General
Power ............................................ 100VAC to 240VAC, 50/60 Hz, 15 watts,
internal, auto-switchable
Temperature/humidity ............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount .................................. Yes, with optional 1U rack shelf,
part #60-190-01
Enclosure type ............................. Metal
Enclosure dimensions ................ 1.75" H x 8.75" W x 9.5" D
4.5 cm H x 22.2 cm W x 24.1 cm D
Shipping weight .......................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International/
National Safe Transit Association)
Approvals ..................................... UL, CE, CUL
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Specifications are subject to change without notice.
Included Parts
Included parts Part number
Lanciaxi 60-213-01
Lanciaxi label 33-244-01
Lanciaxi User’s Manual 68-254-01
Accessories
Accessories Part number
Extron 19" 1U Universal Rack Shelf 60-190-01
S-video male to 2 BNC adapter, female, 8” 26-353-02
S-video female to 2 BNC, male (various lengths) 26-353-xx
BNC male to RCA female adapter 10-264-01
Cables
BNC-4 Mini HR cable is used for RGBS cable runs, and BNC-5
Mini HR cable is used for RGBHV cable runs. Either type can
also be used for composite video, S-video, or RGsB. All Extron
BNC cables have male gender connectors on both ends. A
plenum version of the BNC-5 Mini HR cable is also available.
