Specifications, Part Numbers, Accessories, cont’d
MPX 423 A • Specifications, Part Numbers, Accessories A-6
PRELIMINAR
Y
Cable Type Part number
BNC-5 Mini HR bulk, 1000’ 22-020-03
Plenum BNC-5 Mini HR Cable
Plenum BNC-5 Mini HR bulk, 500’
22-103-02
Plenum BNC-5 Mini HR bulk, 1000’ 22-103-03
Assorted connectors
BNC Connectors Part number
BNC mini HR crimp connectors, qty. 50 100-074-51
SHR male crimp connectors, qty. 50 100-075-51
BNC bulkhead connectors, qty. 50 (for custom wall plates) 100-076-51
Pre-cut cables
BNC-4 Mini HR cable is used for RGBS cable runs. BNC-5 Mini HR cable is used
for RGBHV cable runs. Either type can also be used for composite video, S-video,
or RGsB. All Extron BNC cables have male connectors on both ends. A plenum
version of the BNC-5 Mini HR cable is also available.
Cable Type Part number
BNC-4 Mini HR Cable
BNC-4-25 MHR, 25’
26-210-04
BNC-4-50 MHR, 50’ 26-210-05
BNC-4-75 MHR, 75’ 26-210-06
BNC-4-100 MHR, 100’ 26-210-07
BNC-4-15 MHR, 150’ 26-210-08
BNC-4-200 MHR, 200’ 26-210-09
BNC-4-250 MHR, 250’ 26-210-54
BNC-4-300 MHR, 300’ 26-210-53
BNC-5 Mini HR Cable
BNC-5-25 MHR, 25’
26-260-03
BNC-5-50 MHR, 50’ 26-260-04
BNC-5-75 MHR, 75’ 26-260-16
BNC-5-100 MHR, 100’ 26-260-05
BNC-5-15 MHR, 150’ 26-260-12
BNC-5-200 MHR, 200’ 26-260-06
BNC-5-250 MHR, 250’ 26-260-18
BNC-5-300 MHR, 300’ 26-260-14
N Rolls of bulk cable in lengths up to 5000’ (1524 meters) are available with or
without connectors.
