4-11 MPX 423 A • SIS Programming and Control
PRELIMINAR
Y
Command ASCII Command
(host to switcher) Response
(switcher to host) Additional description
Set subnet mask EX2&
CS
}
Ips
X2&] X2&
= IP address
(###.###.###.###)
Read subnet mask E
CS
} X2&] X2&
= IP address
(###.###.###.###)
Set gateway IP EX2&
CG
}
Ipg
X2&] X2&
= IP address
(###.###.###.###)
Read gateway IP E CG } X2&] X2& = IP address
(###.###.###.###)
Set administrator
password EX3) CA } Ipa X3)] X3) = Password (12 characters,
alphanumeric)
Clear administrator
password
24
E•
CA
}
Ipa•
]
Read administrator
password E
CA
} X3)] X3)
= Password (12 characters,
alphanumeric)
Set user password EX3)
CU
}
Ipu
X3)] X3)
= Password (12 characters,
alphanumeric)
Clear user password 24 E• CU } Ipu• ]
Read user password E CU } X3)] X3) = Password (12 characters,
alphanumeric)
N Password can only be read via RS-232.
Switch Web page
priority
24
EX5$
Cpag
}
Iwp
X5$] X5$
=Web page priority flag
(internal use only):
0 = internal (default power-up)
1 = user
View Web page priority E
Cpag
} X5$] X5$
=Web page priority flag
(internal use only):
0 = internal (default power-up)
1 = user
Set verbose mode 24 EX( CV } Vrb X(] X( = Verbose status:
0 = none (default for Telnet
connection)
1 = Verbose mode (default for
RS-232/RS-422 connection)
2 = Tagged response for
querries
3 = Verbose mode & tagged
response for querries
Read verbose mode E
CV
} X(] X(
= Verbose status:
0 = none (default for Telnet
connection)
1 = Verbose mode (default for
RS-232/RS-422 connection)
2 = Tagged response for
querries
3 = Verbose mode & tagged
response for querries
Read connection’s
security level E
CK
} X3!] X3!
= Connection’s security
level:
11 = user
12 = administrator
