5
©2001 - INLINE, Inc.
IN2200RS Operation Manual - V1.1 01/03/2001
Check the monitor emulation chart and dipswitch settings carefully. An
inappropriate setting of the emulation dipswitches may lead to improper
operation and could even result in severe damage to the computer video
port or the monitor. If users are in doubt as to which monitor emulation to
choose, set all the Monitor Emulation dipswitches to “0” and connect the
local monitor.
8. Connect powered local speakers and / or recording devices to the local audio outputs (if
applicable).
9. Connect power to the IN2200RS using the IN9230 IEC power cable (included).
10. Complete the installation by turning on all computers, local monitors, powered speakers,
data display devices, the IN2200RS and the audio system.
ADAPTER / EXTENSION CABLES FOR INPUT AND LOCAL MONITOR OUTPUT
The IN2200RS has 15-pin HD VGA-type input and local monitor output connector ports. The
following cables / adapters are available:
Computer
3’
6’
12’
25’
35’ +
VGA: 15-Pin HD
Input Cable (M-M)
IN8003M-1 IN8006M-1 IN8012M-1 IN8025M-1 IN80xxM-1
Output Cable (M-F)
IN8006-1 IN8012-1 IN8025-1 IN80xx-1
VGA with Stereo Audio: 15-Pin HD with 3.5mm (M-M) mini DIN
Input Cable (M-M)
IN8203M-1 IN8206M-1 IN8212M-1 IN8225M-1 IN82xxM-1
Output Cable (M-F)
IN8203-1 IN8206-1 IN8212-1 IN8225-1 IN82xx-1
MAC with 15-Pin D:
Input Cable (M-M)
IN9140M IN9144M
Output Cable (M-F)
IN9141
IN9145
MAC G3, G4 and PowerBook with 15-Pin HD*:
Input Cable (M-M)
IN8006M-1 IN8012M-1 IN8025M-1 IN80xxM-1
Output Cable (M-F)
IN8006-1 IN8012-1 IN8025-1 IN80xx-1
SUN: 13W3 (may also be used with SGI with RGsB output)
Input Cable (M-M)
IN9142M IN9146M
Output Cable (M-F)
IN9143
IN9147
Workstation: 5 BNC / RGBHV
Input Cable (M-M)
IN9045-L6 IN9045-L12 IN9045-L25 IN9045-Lxx
Output Cable (M-M)
IN9045-L6 IN9045-L12 IN9045-L25 IN9045-Lxx
Workstation: 4 BNC / RGBS
Input Cable (M-F)
IN9100
*Newer Mac G3 models (with translucent cases) have 15-Pin HD connectors (pins arranged in 3 rows).
Older G3 models (with solid white enclosures) incorporate 15-Pin D connectors (pins arranged in 2 rows).
