SERIAL COMMAND EXAMPLES
The table below provides a sampling of complete serial command strings (including delimiters) and the
responses the IN2200RS might provide after receiving those commands. The bracket [ ] serial delimiters
are used for example purposes. The IN2200RS can be set to recognize four other sets of leading and end
codes: parentheses ( ), braces { }, slashes \ /, and less and greater than < >.
DESIRED FUNCTION
COMMAND STRING
RESPONSE
Request for current system status
[STAT0]
♦
[CH=2, GAIN=1, SHARP=1, VPOS=1,
HPOS=1, FPANEL=ENABLED]
Request for screen shift status (enable / disable,
range and speed)
[STAT1]
[SSHIFT=OFF, RANGE=HI,
SPEED=HI]
Request current input and output sync format
[STAT2]
[CH=2, SYNC OUT=RGBHV]
Request for horizontal and vertical frequencies
(for currently selected input)
[STAT3]
[HFREQ=31,480 Hz, VFREQ=70.1 Hz]
Select input 1
[CH1]
[OK]
Request current channel
[CH?]
[1]
Request current gain value
[GAIN?]
[1]
Set gain to factory default
[GAIN@]
[OK]
Set gain to exact value (0)
[GAIN000]
[OK]
Request horizontal scan rate
[HSC?]
[31,460 Hz]
Request vertical scan rate
[VSC?]
[70.1 Hz]
Request unit firmware version
[INFO]
[Version 1.0]
Request current vertical image position
[PV?]
[1]
Set vertical image position to factory default
[PV@]
[OK]
Set horizontal image position to a predetermined
value of 123
[PH123]
[OK]
Request current horizontal image position
[PH?]
[123]
Set sharpness to factory default
[SHP@]
[OK]
Request current sharpness value
[SHP?]
[126]
Request current screen shift enabled state
[SS?]
[OFF]
Toggle screen shift enable
[SS]
[OK]
Disable screen shift
[SS0]
[OK]
Shift image up 1 unit
[PV+]
[OK]
Shift image down 1 unit
[PV-]
[OK]
Enable screen shift
[SS1]
[OK]
Request current screen shift range
[SSR?]
[HI]
Toggle screen shift range
[SSR]
[OK]
Request current screen shift speed
[SSS?]
[FAST]
Toggle screen shift speed
[SSS]
[OK]
Request for current sync status
[SYNC?]
[RGBHV] (Info responses include
[RGBHV], [RGBS], [RGsB] & [MONO])
Save current setting to configuration memory
[SAVE01]
[OK]
Recall current setting from configuration memory
[CALL01]
[OK]
Error examples
]
[INVALID COMMAND]
[CH3]
[INVALID PARAMETER]
[CCH]
[INVALID COMMAND]
Dipswitch setting conflicts - dipswitches must be changed to enable the function
Select input 1
[CH1]
[INVALID MODE-AUTO SWITCH IS
ENABLED]
Set horizontal image position to factory default
[PH@]
[INVALID MODE-HPHASE DISABLED]
Set vertical image position to factory default
[PV@]
[INVALID MODE-VPHASE DISABLED]
