14

IN2200RS Operation Manual - V1.1 01/03/2001

©2001 - INLINE, Inc.

COMMAND

DESCRIPTION

COMMAND

DESCRIPTION

PHxxx

set horizontal image position to

Channel 2 Horizontal Position

absolute***

baud rate and command code are

PH?

request current horizontal image

general and are not saved for each

position

memory

PV+

image shift up**

SHP+ set

sharpness

(increment)

PV-

image shift down**

SHP- set

sharpness

(decrement)

PV@

set vertical image position to

SHP@

set sharpness (factory default is

normal**

defined in in2200.h)

PVxxx

set vertical image position to

SHPxxx

set sharpness (absolute within limits

absolute**

defined in in2200.h)

PV?

request current vertical image

SHP?

request current sharpness value

position

SS

toggle screen shift enable

RES0

reset (power on)

SS0

disable screen shift

♦♦

(the channel, gain, sharpness, video

SS1

enable screen shift

position, baud rate and command

SS?

request current screen shift enable

codes are reset to their most recent

state

EEPROM values

SSR

toggle screen shift range

RES1

reset

♦♦

SSR0

set screen shift range low

1) the gain, sharpness and video

SSR1

set screen shift range high

♦♦

position for both channels 1 & 2

SSR?

request current screen shift range

are reset to their factory default

SSS

toggle screen shift speed

values

SSS0

set screen shift speed slow

2) screen shift parameters, baud rate

SSS1

set screen shift speed fast

♦♦

and command codes are reset to

SSS?

request current screen shift speed

their factory default values

STAT0

request for general info

3) all configuration memories are ini-

(gain, sharpness, vertical & horizon-

tialized with factory default values

tal position, and state of front panel

4) channel 1 is selected

enable / disable)

SAVExxx

save current settings to configuration

STAT1

request for screen shift info

memory (01 <= xx <= 32) settings

(enable / disable, range and speed)

include:

STAT2

request for output sync format

Channel

STAT3

request for horizontal and vertical

Channel 1 Gain

frequencies

Channel 2 Gain

SYNC?

request for sync info responses

Channel 1 Sharpness

include:

Channel 2 Sharpness

[RGBHV], [RGBS], [RGsB] &

Channel 1 Vertical Position

[MONO]

Channel 2 Vertical Position

VSC?

request vertical scan rate

Channel 1 Horizontal Position

(example response is [12345Hz])

This Command List is preliminary. All commands listed in this manual are functional, however,

INLINE reserves the right to modify, remove and / or add commands on future product revisions. The
commands are not case sensitive.

♦♦

Factory Default enabled by dipswitch

* Only if AUTOSWITCH is disabled by dipswitch

** Only if VERTICAL POSITION is enabled by dipswitch

*** Only if HORIZONTAL POSITION is enabled by dipswitch
