10
IN2200RS Operation Manual - V1.1 01/03/2001 ©2001 - INLINE, Inc.
Switch Panel #1
Switch Function Setting Description
1 Reserved None
1* Auto
Sync format is set automatically based on the number of cables
connected to the unit
2
Output Sync Format
0 Manual Sync format is set via switches #5 & #6
1 Off Disable horizontal position control
3
Horizontal Position
Control
0* On Enable horizontal position control
1 Off Disable vertical position control
4 Vertical Position Control
0* On Enable vertical position control
1* RGBS/
RGBHV Sync format is RGBS or RGBHV depending on the setting of
dipswitch #6
5
Output Sync Format (#2
must be set to 0)
0 RGsB Sync format is sync on green (RGsB)
1 RGBS Sync format is RGBS
6
Output Sync Format (#5
must be set to 1)
0* RGBHV Sync format is RGBHV
1* Forced
(see #8) With RGBHV input signal and RGBHV output signal, the H &
V sync polarities are set with dipswitch #8
7
Output Sync Polarity
(RGBHV In / Out only)
0 Mirror
Input With RGBHV input signal and RGBHV output signal, the V &
H sync polarities are the same as the input
1* Negative
With RGBHV input signal and RGBHV output signal, the H &
V sync polarities are negative, negative
8
Output Sync Polarity
(RGBHV In / Out only)
0 Positive
With RGBHV input signal and RGBHV output signal, the H &
V sync polarities are positive, positive
1 Remove
The output sync will not have serration pulses when set for
RGBS or RGsB output
9
RGBS / RGsB Output
serration pulses
0* Present
The output sync will have serration pulses present when set for
RGBS or RGsB output
10 Reserved None
Switch Panel #2:
Switch Function Setting Description
1 Emulation On Monitor emulation is always ON for Input 1
1
Input 1 Monitor
Emulation
0* Automatic Monitor emulation is automatic. Emulation is ON when there
is no local monitor present and off when there is a local
monitor (switch #2 must be ON)
1 Off Disable Auto Emulation
2
Input 1 Auto
Emulation
0* On Enable Auto Emulation (switch #1 must be set to 0)
1 Emulation On Monitor emulation is always ON for Input 1
3
Input 2 Monitor
Emulation
0* Automatic Monitor emulation is automatic. Emulation is ON when there
is no local monitor present and off when there is a local
monitor (switch #2 must be ON)
1 Off Disable Auto Emulation
4
Input 2 Auto
Emulation
0* On Enable Auto Emulation (switch #1 must be to 0)
1* Enable Enable the front panel operation
5
Front Panel
Operation
0 Disable Disable the front panel
1 On
An input is selected automatically based on the presence of
sync. Input 2 has the higher priority
6
Automatic Input
Selection
0* Off Manual input selection
7 Reserved None
8 Reserved None
9 Reserved None
10 Reserved None
* Factory Default
