19
©2001 - INLINE, Inc. IN2200RS Operation Manual - V1.1 01/03/2001
Specifications
IN2200RS High-Resolution Computer Video Interface
Input
Video Connectors
(2) 15-Pin HD female
RGB Signals Analog video, 1.5 Vp-p max
Sync Signals TTL Format: RGBHV, RGBS or RGsB
Sync Range Horizontal: 30 - 130 KHz Vertical: 30 - 120 Hz
Stereo Audio (2) 3.5mm Stereo Mini Impedance: 10 Kohm
Output
Buffered Local Monitor
(2) 15-Pin HD Female
Main Output Connectors 2 sets of (5) female BNC
Stereo Audio (2) 3.5mm Stereo Mini female Impedance: 50 ohm
Signal Format RGBHV, RGBS or RGsB
Gain Range 0.0 (black) to 1.2 (20% voltage increase)
Bandwidth 300 MHz @ -3 dB with 0.7 Vp-p input signal
General
Power Supply
Internal Switch Mode: 90-260 VAC; 0.29 A; 47-63 Hz
RS-232 Serial Port 3-Pin Captive Screw Terminal
RS-232 Protocol 2400 to 38,400 bps, 8 Bits, I stop Bit, No parity
Shipping Weight 6 lbs. / 3 Kg
Product Weight 4 lbs. / 1.8 Kg
Dimensions 1.75” x 11.75” x 8.1” / 4.4cm x 29.8cm x 20.6cm
Regulatory Approvals UL1950, CAN/CSA-22.2 No. 950, 3
rd
Edition
CE: EN55022 (1987), EN50081-1 (1991),
EN50082-1 (1992 & 1994), EN60950-92
Included Accessories
IN9230 IEC Power Cable, 6’ long (USA only)
Operations Manual
Optional Accessories
VGA Monitor Adapter and Extension Cables
Input and Local Monitor Adapter and Extension Cables:
IN8000 Series - 15-pin HD male to 15-pin HD female, various lengths from 3’ to 100’
For Other Computers: Refer to the Adapter / Extension Cables for Input and
Local Monitor Output Table on page 5
Stereo Audio Cables
IN9106 - (1) 3.5mm Stereo Mini Male to (1) 3.5mm Stereo Mini Male, 6' long
IN9107 - (1) 3.5mm Stereo Mini Male to (1) RCA Stereo Male, 6' long
Rack-Mount Hardware
IN9129 - One Pair Rack Ears - Mounts IN2200RS in 1U Rack Space
Miscellaneous Accessories
IN9120 - Heavy Duty Carrying Case for IN2200RS, Input Cables and Output Cables
