Installation

This section offers step-by-step instructions for installing the IN2200RS. An Application
Diagram is provided on page 6. Illustrations showing Front Panel Controls and Rear Panel
Connectors can be found on page 7.

1. Place / install the IN2200RS at the desired location. Make sure that the unit is seated on
a flat surface or is securely installed in a standard 19” equipment rack in a 1-U rack space
(using the optional IN9129 Rack Ears).

2. Set the dipswitches for the requirements of your installation (see the Dipswitch Settings
Chart on page 10).

3. Connect the IN2200RS video output (5 BNC connectors) to the data display device’s
RGB input using high-resolution BNC cables or a multi-conductor RGBHV, RGBS or RGsB
“snake.” The IN7000 Series, IN7200 Series, IN7300 Series and IN7400 Series high-
resolution cables are well suited for this purpose. While making connections, take care to
ensure that the red output is connected to the red input, green output is connected to the green
input, etc.

4. Connect the IN2200RS main audio outputs (3.5mm female jacks for left and right channel
signals) to the audio system’s input (mixer or amplifier). The main audio output signal is line
level and can be set for unbalanced (factory default) or balanced. The output is compatible
with any audio system that accepts a line level signal, and can be easily connected with an
IN9106 audio cable. For audio systems with RCA connectors, use the IN9017 audio adapter
cable.
Note: Cable wiring configurations for balanced / unbalanced output signals and internal
control adjustments can be found on pages 16 & 17.

5. Connect the computer graphics card to the IN2200RS 15-pin video input port.

•

PC / MAC / SGI Computers with 15-pin HD Video Ports - can be connected via
IN8000M-1 / IN8200M-1 Series high-resolution coaxial VGA cables.

•

Older Macintosh (15-pin D) / SUN (13W3) / Workstations (4 or 5 BNC) - can be
connected using the appropriate input / output cables listed in the chart on the following
page.

6. Connect the computer sound card output (if applicable) to the IN2200RS 3.5mm female
stereo audio input connector using an IN8200-1 Series cable [15-pin HD with 3.5mm (M-M)
mini DIN], or an IN9106 audio patch cable (3.5mm stereo mini male to 3.5mm stereo mini
male). For computers with RCA connectors, use the IN9107 audio adapter cable [(1) 3.5mm
stereo mini male to (2) RCA male].

7. Connect the local computer monitor (if present) to the local monitor output port of the
IN2200RS. Monitors with 15-pin VGA connectors will attach directly to the interface. For
other types of monitors, use the appropriate monitor output adapter cable (see the list on the
following page). If no local monitor is used, set the monitor emulation dipswitch to emulate
a color VGA or 13/14” MAC RGB monitor (see the Dipswitch Settings chart on page 10).
