2
IN2200RS Operation Manual - V1.1 01/03/2001 ©2001 - INLINE, Inc.
Product Overview
DESCRIPTION
The IN2200RS is a high-performance video interface for analog video signals including VGA,
SVGA, XGA, SXGA, UXGA, MAC, SUN, SGI and other high-resolution workstations. The
IN2200RS includes an impressive range of features and signal adjustments, yet retains a clean,
uncluttered appearance and amazingly simple operation.
The IN2200RS is not a scan converter. The data projector, monitor or
other output device must be compatible with the horizontal scan rate,
vertical scan rate and resolution output by the computer video card.
•
Two Video Inputs with Local Monitor Outputs - offer flexibility in a variety of
applications.
•
32 Memories - When an input is selected, previously stored position, gain and sharpness
settings for that input are automatically recalled.
•
Three Switching Modes - In Manual Mode, users select the desired input by pressing a
large front panel input button. In Auto Switch Mode, the unit automatically selects the
active input. If more than one input is active, the highest numbered input has priority.
Remote Switching is done via RS-232 control.
•
RS-232 Serial Control - is provided for all interface functions and facilitates complete
system integration and effortless control when combined with a third party control
system.
•
Stereo Audio-Follow-Video Switching - When Input 1 or 2 is selected, the video signal
and the associated stereo audio signal are simultaneously switched to the output.
•
Large Backlit LCD Display - simultaneously shows the horizontal and vertical
frequencies of the current input signal.
•
15-Pin HD VGA Standard Connectors - The IN2200RS connects directly to VGA
graphics cards and VGA local monitors.
•
High-Resolution Amplification - The IN2200RS provides superb performance with
analog video signals at virtually any resolution and refresh rate.
•
Output Sync Optimization - Dipswitches set the interface output sync signals for
optimal operation with LCD, DMD, D-ILA and Plasma Data Grade Display devices.
•
Flexible Output Sync with Automatic Output Sync Selection - The unit can be set for
an RGBHV, RGBS or RGsB output signal to match the requirements of the data display
device and signal distribution system.
