Surface Access Products • Introduction Surface Access Products • Introduction
Introduction
2
Chapter Two
Installation
Installation Overview
Preparing the Routing Template
Preparing the Table and Mounting the Enclosure
Cabling and Installing the AAPs
Bezels
1-4
The HSA 800 and HSA 802 are available in a variety of surface
finishes, including black anodized metal, brushed aluminum,
brushed brass, polished aluminum, and polished brass.
Features
• UL listed
• Easy access to connectors and controls
• Durable mechanical movement and latching mechanism
• Available in a variety of surface finishes
• Includes a variety of RJ-45 connector bezel colors: black,
red, blue, orange, gray, white, ivory, yellow, and green
• Compact size
• Easy installation of two or four double-space Extron
AAPs
• RJ-45 (CAT 5/6) network and data connections
• Grounded AC plug(s)
