Surface Access Products • Reference Information Surface Access Products • Reference Information
Reference Information, cont’d
-or-
A-4
HSA 800/802 EU Part number
HSA 802 EU Enclosure (polished aluminum) 60-418-24
HSA 802 EU Enclosure (brushed brass) 60-418-25
HSA 802 EU Enclosure (polished brass) 60-418-26
HSA 800/802 UK Part number
HSA 800 UK Enclosure (black anodized) 60-417-41
HSA 800 UK Enclosure (brushed aluminum) 60-417-43
HSA 800 UK Enclosure (polished aluminum) 60-417-44
HSA 800 UK Enclosure (brushed brass) 60-417-45
HSA 800 UK Enclosure (polished brass) 60-417-46
HSA 802 UK Enclosure (black anodized) 60-418-41
HSA 802 UK Enclosure (brushed aluminum) 60-418-43
HSA 802 UK Enclosure (polished aluminum) 60-418-44
HSA 802 UK Enclosure (brushed brass) 60-418-45
HSA 802 UK Enclosure (polished brass) 60-418-46
HSA 800/802 Australian Part number
HSA 800 Aus Enclosure (black anodized) 60-417-61
HSA 800 Aus Enclosure (brushed aluminum) 60-417-63
HSA 800 Aus Enclosure (polished aluminum) 60-417-64
HSA 800 Aus Enclosure (brushed brass) 60-417-65
HSA 800 Aus Enclosure (polished brass) 60-417-66
HSA 802 Aus Enclosure (black anodized) 60-418-61
HSA 802 Aus Enclosure (brushed aluminum) 60-418-63
HSA 802 Aus Enclosure (polished aluminum) 60-418-64
HSA 802 Aus Enclosure (brushed brass) 60-418-65
HSA 802 Aus Enclosure (polished brass) 60-418-66
Included Parts
Part Part number
HSA 800/802 HSA Hideaway Products manual 68-617-01
Snap-in icon inserts 40-348-01
RJ-45 connector bezel plug-in inserts
(assorted colors and blank)
70-201-01
1/4 - 20, 1”, 1-1/2”, 2”, 2-1/2” full thread bolts
M6 x 65mm, 50mm, 40mm, 25mm full thread bolts
Routing Template and Replacement Parts
Part Part number
HSA 800/802 routing template 70-191-01
HSA 800/802 standard (10-lb) gas lift 70-193-01
HSA 800/802 12-lb gas lift 70-193-02
HSA 800/802 15-lb gas lift 70-193-03
HSA latch replacement kit 70-194-01
Interface Accessories
Accessory Part number
RGB 580xi 60-362-01
RGB 580xi AAP 3’ (black) 70-128-02
RGB 580xi AAP 6’ (black) 70-129-02
RGB 580xi AAP 12’ (black) 70-130-02
RGB 580xi I AAP 3’ (black) 70-131-02
RGB 580xi I AAP 6’ (black) 70-132-02
RGB 580xi I AAP 12’ (black) 70-133-02
RGB 580xi S AAP 3’ (black) 70-134-02
RGB 580xi S AAP 6’ (black) 70-135-02
RGB 580xi S AAP 12’ (black) 70-136-02
RGB 580xi SI AAP 3’ (black) 70-137-02
RGB 580xi SI AAP 6’ (black) 70-138-02
RGB 580xi SI AAP 12’ (black) 70-139-02
A-5
