2. If you have not previously updated firmware for the FOXBOX unit before, on the Add
Device screen (see figure 22), select the RS-232 tab.
Figure 22. Add Device Screen
If you have previously updated firmware for this model, click Cancel. The Firmware
Loader window appears. Proceed to step 5.
NOTE: Although the screen also has a TCP/IP tab, the FOXBOX unit does not have a
LAN port. Do not select the TCP/IP tab.
3. From the drop-down menus on the RS-232 screen, select the appropriate Com port
number and baud rate (the default is 9600).
4. Click OK. The Firmware Loader window appears (see figure 23).
5
Figure 23. Extron Firmware Loader Window
5. Select the FOXBOX unit and click File > Open. The Choose Firmware File screen
appears (see figure 24).
6
6
Figure 24. Choose Firmware File Window
FOXBOX Tx/Rx HDMI • Remote Control 34
