Installation and
Operation

This section describes procedures to cable, connect, and manually operate the
FOX T UWP 302. Topics in this section include:

Installation Overview

Rear Panel Features

Front Panel Features

Mounting and Making Connections

Operation

Installation Overview

Install the FOX T UWP 302 into an electrical UL Listed junction box.

CAUTION: Risk of personal injury. Failure to check the items listed below may result

in personal injury.

ATTENTION: Failure to check the items listed below may result in property damage.

1.

Check that installation of an electrical UL Listed junction box meets local and state
building, electrical, and safety codes.

2.

Install the junction box according to the junction box installation instructions.

3.

Prepare and pull the cables through the junction box.

TIP: Secure cables with clamps or ties to provide strain relief.

4.

Trim back and insulate shields with heat shrink.

ATTENTION: To prevent short circuits, the outer foil shield can be cut back to the

point where the cable exits the cable clamp. Both braided and foil shields should
be connected to an equipment ground at the other end of the cable.

5.

Connect cables to the rear panel connectors (see

Rear Panel Features

on page 5).

6.

Mount the FOX T UWP 302 enclosure into the junction box (see

Mounting

on page 8).

7.

Configure the FOX T UWP 302 with SIS commands (see

Simple Instruction Set

Control

on page 13) or the FOX Extenders control program (see

FOX Extenders

Control Program

on page 21).

8.

Install the faceplate (see

Mounting

on page 8).

4

FOX T UWP 302 Wallplate Transmitter • Installation and Operation
