Installation Checklist
Determine which source will be used for the EDID information and configure the DDC
switches appropriately ( see pages 13 to 16) . If necessary, use the EDID Minder to read and
store information from a display ( see pages 13 to 14 ).
Prepare twisted pair cables ( see “Terminating shielded cable” ).
Connect the transmitter to the receiver ( see “Connections” )
Connect the source device to the transmitter ( see “DVI-D input” ). Do not power on the
source device at this time.
Connect the display device to the receiver ( see “DVI-D output” ). If required, connect a local
monitor to the transmitter.
If required, connect any RS-232 or IR control devices ( see “Control pass-through” ).
Connect the power supply to the transmitter ( see “Power input” ).
CAUTION: Read all the Cautions in the “Power Input” section.
Power on the display device.
Power on and boot up the source device.
