Reference
Information
This section provides information about:
z Specifications
z
Included Parts
z Optional Accessories
Specifications
Video
Maximum data rate ....................... 10 Gbps (3.3 Gbps per color)
Maximum pixel clock ..................... 330 MHz (165 MHz per link)
Resolution range ............................ Up to 2560x1600 @ 60 Hz
Formats ......................................... RGB and YCbCr digital video
Standards ...................................... DVI 1.0, HDMI 1.2
Video input and loop-through— transmitter
Number/signal type ........................ 1 dual link DVI-D* input
1 dual link DVI-D* local loop-through
Connectors .................................... 2 DVI-I female (1 for input, 1 for loop-through)
NOTE: *Dual link DVI is backwards compatible with all single link DVI/HDMI
signals.
Interconnection between transmitter and receiver
Connectors .................................... (3) RJ-45 per unit for 3 cables connecting the transmitter and
receiver
Termination standards .................... TIA/EIA T568A or T568B
Signal transmission distance
1920x1200 or 1080p @ 60 Hz
Extron DTP26 cable .................... Up to 150’ (45 m)
2560x1600 @ 60 Hz
CAT 5/5e/6 STP or Extron DTP26 Up to 125’ (38 m)
CAT 5/5e/6 UTP cable ................ 100’ (30 m)
Longer distances are possible with lower rates.
NOTE: The transmission distance varies greatly depending on the signal resolution
and on the type of cable, graphics card, and display used in the system.
DVI DL 201 Tx/Rx • Reference Information 19
