6. Boot up the source device. The source boots with the resolution and refresh rate of
the remote display.
NOTE: Because the remote display is the source of EDID, it must be powered on
before the source device is booted.
7. Power on the local monitor, if required.
NOTE: The remote display device must be capable of handling a resolution equal
to or greater than that of the local monitor.
Setup and Operation
1. Determine which source will be used for the EDID information and configure the DDC
switches appropriately (see
pages 13 to 16 ). If necessary, use the EDID Minder to read
and store information from a display (see pages 13 to 14 ).
2. Prepare twisted pair cables (see “Terminating shielded cable” ).
3. Connect the transmitter to the receiver (see “Connections” )
4. Connect the source device to the transmitter (see “DVI-D input” ). Do not power on
the source device at this time.
5. Connect the display device to the receiver (see “DVI-D output” ). If required, connect
a local monitor to the transmitter.
6. If required, connect any RS-232 or IR control devices (see “Control pass-through” ).
7. Connect the power supply to the transmitter (see “Power input” ).
CAUTION: Read all the Cautions in the “Power Input” section.
8. Power on the display device.
9. Power on and boot up the source device.
DVI DL 201 Tx/Rx • Configuration and Operation 16
