pH 7310 Printer (only pH 7310P)
ba75929e03 12/2011 55
10.2 Operation / printing
Data are only output to the printer if the following conditions are met

Data are transmitted manually or automatically (see section 9.1 O PTIONS
FOR DATA TRANSMISSION , page 52)
 the printer is switched on (LED illuminated)
 there is no USB connection.
10.3 Printer settings
To open the Storage & config menu, press the [Menu] key in the mea-
sured value display. After completing the settings, switch to the measured
value display with .
Default settings are printed in bold.
10.4 Maintenance
10.4.1 Changing the roll of paper
Menu item Possible set-
ting Description
System / Printer /
Font size
12x20
8x16
7x16 Select the font size for the printer
A print sample (character set of the
printer) to view the available font
sizes can be printed with >.
System / Printer /
Print test page
- The printer prints the meter informa-
tion from the System
/ Service infor-
mation
menu.
The current printer settings are
used for the printout
.
1. Pull the lever (3) until the lid (4) of the paper compartment opens.
2. If necessary, remove any remains of the old roll of paper.
3. Insert the new roll of paper. The start of the paper should poke out of the
paper compartment.
4. Close the lid (4) of the paper compartment so that it clicks into place.
5. If necessary, move the printer paper forward with .
