pH 7310 Operation
ba75929e03 12/2011 17
4.4.3 Menus and dialogs
The menus for settings and dialogs in procedures contain further subelements.

To select a subelement, use the <><> keys. The current selection is dis-
played with a frame.
 To make further settings, switch to the next higher menu level with
[Back].
 Use to return to the measured value display.
4.4.4 Elements in menus and dialogs
 Submenus
The name of the submenu is displayed at the upper edge of the frame. Sub-
menus are opened by confirming with . Example:
 Settings
Settings are indicated by a colon. The current setting is displayed on the
right-hand side. The setting mode is opened with . Subsequently,
the setting can be changed with <><> and . Example:
Operating
mode Description
Measuring The measurement data of the connected sensor are shown
in the measured value display
Calibration The course of a calibration with calibration information, func-
tions and settings is displayed
Storage in
memory The meter stores measuring data automatically or manually
Transmit-
ting data
The meter transmits measurement data and calibration
records to the USB interface automatically or manually.
Setting The system menu or a sensor menu with submenus, set-
tings and functions is displayed
General
Interface
Clock
Service information
Reset
System
01.07.2011
08:00
Back
