Maintenance, cleaning, disposal Turb 430 IR/T
52 ba75507e03 07/2006
5.1.2 Retrofitting the accumulator pack
Caution
Use original WTW accumulator packs only.
Together with the power pack the accumulator pack is available as an
accessory (see section 8.1).
1 Open the battery compartment:
– Unscrew the two screws (1) on the underside of the meter,
– Remove the lid of the battery compartment (2).
2 If necessary, take four old batteries out of the battery
compartment.
3 Connect the cable of the accumulator pack with the socket (3)
on the bottom of the battery compartment and insert the
accumulator pack in the battery compartment.
4 Close the battery compartment and fix it with the screws.
1
2
3
