Turb 430 IR/T Commissioning
15 ba75507e03 07/2006
3.3 Connecting the LabStation
Note
The LabStation is available as an accessory (see section 8.1).
In order to use the functions of the LabStation for operation in the
laboratory, connect the LabStation and place the Turb 430 IR/T in the
LabStation.
Connecting the
LabStation (optional)
1 If necessary, replace the Euro plug (1) on the power pack (2)
by the country-specific plug suitable for your country.
2 Connect the plug (3) to the socket (4) of the LabStation.
3 Connect a PC or printer to the socket (5) of the LabStation as
necessary.
4 Connect the power pack to an easily accessible power socket.
5 Place the Turb 430 IR/T in the LabStation.
5
4
3
2
1
