Turb 430 IR/T Operation
21 ba75507e03 07/2006
4.3 General operating principles
This section contains basic information on the operation of the
Turb 430 IR/T.
Operating elements,
display
An overview of the operating elements and the display is given in
section 1.2 and section 1.3.
Operating modes,
navigation
An overview of the operating modes of the Turb 430 IR/T and the
navigation through menus and functions can be found in section 4.3.1
and section 4.3.2.
4.3.1 Operating modes
The instrument has the following operating modes:
! Measurement
The display indicates measurement data in the measured value
display
! Calibration
The display indicates a calibration procedure with calibration
information
! Data transmission
The meter transmits measuring datasets or calibration records to the
serial interface
! Configuration
The display indicates a menu with further menus, settings and
functions
4.3.2 Navigation
Measured value display In the measured value display, open the menu with
Menus and dialogs The menus for settings and dialogs in courses contain further
submenus. The selection is made with the <
▲> <▼> keys.
The current selection is displayed in reverse video.
! Menus
The name of the menu is displayed at the upper edge of the frame.
Menus are opened by confirming with . Example:
